Pipe Relining Charlestown

Pipe relining Charlestown repairs a cracked or root-damaged drain by installing a resin liner inside the old pipe, so the yard stays shut while the faults get sealed from within. We film the line first, name a fixed figure, and only then line it. Ring (02) 4063 3469 to book the camera check that settles whether your pipe is a candidate.

Call (02) 4063 3469 Request a quote

Licensed plumbers and gas fitters · NSW Lic. 359278C

Last updated September 2026

Which faults does a liner fix?

Relining suits a pipe that is damaged but still standing. The liner bonds to the inside wall, so anything short of a collapse can be sealed in one pass.

Root masses threading through open joints in old clay
Hairline cracks that weep wastewater into the surrounding soil
Silt catching in sagging sections and snagging everything that flushes past
Offsets where one pipe length has dropped out of line with the next

If the camera shows a barrel broken into pieces, no liner will hold. That pipe needs digging up, and the quote says so rather than pricing a liner that cannot work.

How We Reline a Drain

The sequence is straightforward, and the footage settles each decision along the way.

01
Prove the pipe is sound
The CCTV inspection maps the damage and confirms the barrel can carry a liner. Nothing gets quoted off a guess.
02
Strip the wall clean
The jetter takes roots, scale and silt off the pipe so the resin bonds to clay, not to the muck sitting on it.
03
Roll the liner in
A resin-soaked felt tube is pulled or inverted into place, then left to harden into a smooth new bore.
04
Film it finished
You see the sealed pipe on screen before the line goes back into service.

What decides the price of a reline?

We provide up-front, honest quotes that will always match the final price, should you decide to go ahead.

It costs nothing to get us out to your door (excluding after-hours).

The figure moves with:

The length of damaged run, measured straight off the footage
How many joints or cracks need sealing along it
The pipe diameter and where the access openings sit
Whether roots have to be jetted out before the liner can go in

Why older Charlestown streets are reline country

The pipes here all share a birthday

Sewerage reached the suburb as one 1959 program, so the clay house drains under the postwar front yards went into the ground together and have worn out together too. They give out at the joints rather than along the barrel, which is exactly the fault a liner seals.

The ground works those joints loose

Reactive clay under the ridge swells in a wet month and shrinks through a dry one, dropping collars out of alignment. A line that has been jetted clear twice in a year usually has open joints worth sealing, not another clearing bill.

Digging costs more than the pipe

Under the postwar brick-veneer and weatherboard houses, drains often run beneath driveways, paths and garden beds. A trench means breaking and relaying everything above the pipe, while a liner is fed in from the existing openings.

When We're Not the Right Call

A collapsed pipe gives the resin nothing to bond to, so excavation is the only fix there. A fault in the water authority's main past your boundary is reported to them, not relined at your cost.

What Customers Say

They were very understanding of my situation, with a work around for my pipe issues, which ended up being a fraction of the cost than previous quotes from another company.

Sarah

Where the work connects

The blocked drains hub covers clearing and what causes it, and a CCTV drain inspection always comes first, because lining without footage is a guess. Where roots are the culprit, tree root removal handles the clearing side, and blocked sewer work covers the main line. For faults that cannot wait, emergency plumbing covers after-hours calls, and taps, hot water and gas sit with the same plumber in Charlestown.

Pipe relining questions from locals

How long does a relined pipe last?

A well-installed liner becomes the new pipe wall, sealing the cracks and joints that were letting water out and roots in. The work carries our 365-day warranty on all work, and the after footage shows you exactly what got sealed.

Can you reline the clay drains under an older house here?

Usually, yes. The clay house drains from the 1959 sewer program are relining candidates as long as the camera shows the barrel has not caved in. We film first and tell you straight whether a liner or a dig-up is the better spend.

Does relining work under driveways and gardens?

That is where it earns its keep. The liner goes in through the access points the pipe already has, so concrete, paving and planted beds stay whole instead of being trenched open and patched.

How do I book a relining quote?

Ring (02) 4063 3469 or send the form. The job starts with a camera inspection so the quote matches the real state of the pipe, and the figure we agree on is the one on the invoice.
